1.47 inch IPS TFT LCD 172*320 High Brightness 700 cd/m² MCU Interface

This is a small-sized TFT LCD display,  1.47 inch TFT LCD with 172*320 resolution, of portrait rectangular shape. It supports 262K colors and can clearly display color images. The display uses an IPS technology for wide viewing angles, offering high brightness and high contrast. It has an MCU interface with a 24-pin connector. The overall thickness of the display module is only 1.6mm, making it suitable for electronic devices with limited space.

Product Drawing：

Product Specification:

Product Feature:

• Small Size:  The 1.47-inch screen is specifically designed for portable and compact devices.
• High Resolution:  With a resolution of 172×320 pixels, it ensures clear display of both images and text.
• Rich Colors:  Supports 262K color display, offering vibrant and rich colors that make images more vivid and realistic.
• Portrait Mode Display: The rectangular form factor seamlessly integrates into various small electronic devices.
• Rounded Corners Shape:  The rounded corner design not only enhance stylish and aesthetic appeal but also improve the comfort when holding the device.
• IPS Technology:  Utilizing IPS TFT LCD technology, it achieves a 170° ultra-wide viewing angle, providing a consistent visual experience from any angle.
• High Contrast:  With an ultra-high contrast ratio of 1300:1, the colors are more vivid and the details more pronounced.
• High Brightness: The screen surface brightness reachs 700cd/m², ensuring clear visibility even in bright environments.
• Slim Design:  The overall thickness of the 1.47 inch TFT module is just 1.6mm, making it exceptionally thin and space-efficient.

Applications:

Choosing this 1.47-inch TFT LCD rounded corner display module will bring unprecedented visual enjoyment to your devices. Whether it's the high-precision requirements of professional medical equipment or the fashion and portability of smart wearable products, we can provide you with the best display solutions.

Medical Equipment: Such as blood oxygen meters, ECG machines, etc., requiring high precision and high-definition display of patient data.

Handheld Testing Instruments: In fields like environmental monitoring and water quality testing, it intuitively displays test results.

Smart Wearables: Smart bracelets, smartwatches, etc., providing clear display of time, health data, and other information.
